Single Phase 230 V 50 Hz 1.0 PF 1500 RPM Water I Air Cooled
KVA	KW	H.P	AMP	BORE	CYLINDER	FLYWHEEL Casting (Kg)	NET WT. (kg)
3	3	5	12	85	SINGLE	34 KG	140 KG
4	4	6.	16	85	SINGLE	45 KG	170 KG
5	5	8	20	87	SINGLE	48 KG	200 KG
6	6	10	24	95	SINGLE	58 KG	230 KG
7.5	7.5	12	28	102	SINGLE	64 KG	255 KG
8	8	12	36	114	SINGLE	70 KG	270 KG
10	9	14	40	114	SINGLE / DOUBLE	80 KG	300 KG
12.5	12.5	16	48	95	SINGLE / DOUBLE	70 KG	350 KG
15	14	24	56	102	DOUBLE	70 KG	400 KG
20	18	28	64	114.3	DOUBLE	80 KG	450 KG
25	22	32	67	116	DOUBLE	100 KG	500 KG

THREE PHASE 415 V 50 HZ 0.8 PF 1500 RPM WATER I AIR COOLED
KVA	KW	H.P	AMP	BORE	CYLINDER	FLYWHEEL Casting (Kg)	NET WT. (kg)
6	5	10	8	87	SINGLE	48 KG	240 KG
7.5	7.5	12	10	95	SINGLE	58 KG	265 KG
8.5	8.5	12	11	102	SINGLE	64 KG	280 KG
10	9.5	14	13	114	SINGLE / DOUBLE	70 KG	310 KG
12.5	12.5	16	16	114	SINGLE / DOUBLE	80 KG	360 KG
15	14.5	24	23	102	DOUBLE	70 KG	410 KG
20	18.5	28	26	114	DOUBLE	80 KG	460 KG
25	22	32	67	116	DOUBLE	100 KG	510 KG

PRODUCT SPECIALITIES :

• RADIATOR (100% COPPER).
• ALTERNATOR (100% COPPER).
• INSULATION H CLASS.
• ALTERNATOR - MS BODY(NO BURNING & PREVENT HEAT).
• C.R. - KIRLOSKAR.
• BEARINGS - NBC / SKF.
• CASTING - HIGH GRADE & EXPORT QUALITY FINISHING.
• LINER / PISTON - USHA.
• CRANKSHAFT / CONNECTING ROD - EN9 HARDENED.
• AIR CLEANER / SILENCER - NICKEL.
• GEAR COVER / SIX HOLE PLATE - CAST IRON.
• FULE INJECTION PUMP - MICO(BOSCH).
• FUEL TANK - SEAMLESS WELDING.
• FLYWHEEL - AS PER KIRLOSKAR STANDARDS.
• FUEL CONSUMPTION (ON 80% LOAD) - 200GM/KW-HR.
• 100% GENUINE SPARE PARTS
